Angular contact ball bearings / Angular contact ball bearings
Request a call back
1) This description is for informational purposes only and we assume no responsibility for any inaccuracies, errors, etc.
2) The weight of less than 0.001 kg is indicated as 0.001 kg
3) The sketch does not contain all the design features of the productGo to purchase
Bearing CRAFT 7304 AC
|
Are available
|
| Price: | 123 uah |
| Quantity: |
Are available
| Price : | 123 uah |
| Quantity : | |
| Brand | Country of origin of the brand |
|---|---|
| CRAFT | Lithuania |
The dispatch of the goods is carried out within 1-2 banking days from the order day!
Look at the prices for analogues-substitutes:
| Name | Brand | Photo | Video | Dimensions | Price / Availability |
|---|---|---|---|---|---|
|
Angular contact ball bearing Bearing 20х52х15 7304 ACM |
PRC |
|
d: 20 D: 52 B: 15 Analogues |
127 грн.
Are available
|
|
|
Angular contact ball bearing Bearing 7304 ACM |
CRAFT |
|
d: 20 D: 52 B: 15 Analogues |
185 грн.
Are available
|
|
|
Angular contact ball bearing Bearing ZVL 7304AA |
ZVL |
 |
d: 20 D: 52 B: 15 Analogues |
604 грн. Goods expected Notify me of admission Request a call back |
Look at the prices for analogues-substitutes:
| Notation | Brand | Photo | Dimensions | Price for 1 pc. / Availability |
|---|---|---|---|---|
|
Angular contact ball bearing Bearing 20х52х15 7304 ACM |
PRC |
|
d: 20 D: 52 B: 15 Analogues |
127 uah
Are available |
|
Angular contact ball bearing Bearing 7304 ACM |
CRAFT |
|
d: 20 D: 52 B: 15 Analogues |
185 uah
Are available |
|
Angular contact ball bearing Bearing ZVL 7304AA |
ZVL |
|
d: 20 D: 52 B: 15 Analogues |
604 грн. Goods expected Notify me of admission Request a call back |
Sketch
Characteristics:
(CRAFT 7304 AC)
| Bearing inner diameter d,mm | d | 20 | mm |
| Bearing outside diameter D,mm | D | 52 | mm |
| Bearing height (width) B,mm | B | 15 | mm |
| Dynamic load rating | C | 17.4 | kN |
| Static load rating | Co | 9.4 | kN |
| Limiting speed of rotation, plastic grease | npl | 17000 | r/min |
| Limiting speed of rotation, liquid lubrication | nl | 21000 | r/min |
| 0.15 |
2) The weight of less than 0.001 kg is indicated as 0.001 kg
3) The sketch does not contain all the design features of the product
