Bearings / Bearings
1) This description is for informational purposes only and we assume no responsibility for any inaccuracies, errors, etc.
2) The weight of less than 0.001 kg is indicated as 0.001 kg
3) The sketch does not contain all the design features of the productGo to purchase
Bearing ENDURO 3903 LLU 17*30*10
| Brand | Country of origin of the brand |
|---|---|
| Enduro | USA |
The dispatch of the goods is carried out within 1-2 banking days from the order day!
Look at the prices for analogues-substitutes:
| Name | Brand | Photo | Video | Dimensions | Price / Availability |
|---|---|---|---|---|---|
|
Automotive ball bearing Bearing 3903-2RS 17x30x10 |
PRC |
|
d: 17 D: 30 B: 10 Analogues |
1106 грн.
Are available
|
Look at the prices for analogues-substitutes:
| Notation | Brand | Photo | Dimensions | Price for 1 pc. / Availability |
|---|---|---|---|---|
|
Automotive ball bearing Bearing 3903-2RS 17x30x10 |
PRC |
|
d: 17 D: 30 B: 10 Analogues |
1106 uah
Are available |
Sketch
Characteristics:
(ENDURO 3903 LLU 17*30*10)
| Bearing inner diameter d,mm | d | 17 | mm |
| Bearing outside diameter D,mm | D | 30 | mm |
| Bearing height (width) B,mm | B | 10 | mm |
| Dynamic load rating | C | 5.55 | kN |
| Static load rating | Co | kN | |
| Limiting speed of rotation, plastic grease | npl | r/min | |
| Limiting speed of rotation, liquid lubrication | nl | r/min | |
| 0.026 |
2) The weight of less than 0.001 kg is indicated as 0.001 kg
3) The sketch does not contain all the design features of the product
Video Viewed
Application
First of all, this bearing is used for old carriages with a square cone. The double row design greatly reduces the flex of the bottom bracket spindles and doubles the bearing contact area, while requiring approximately 25% less width than two single row bearings. Sealed and 90% filled with high pressure waterproof grease to withstand daily misuse. These bearings are made of high carbon chromium steel. Always designed with the deepest possible groove tracks to accommodate the largest balls and feature double lip seals that travel in micro grooves to form a complete maze to provide superior protection to internals.
