1580205

Bearing 1580205 оIt is classified as a combine bearing. By type is a single-row ball, perceiving radial loads. Has the sizes of 25 * 52 * 15 mm. The design feature is a spherical seating surface of the outer ring (cage). The inner ring has a cylindrical fit. Closed with rubber seals that protect against moisture, dust and other contaminants, as well as prevent leakage of lubricant. The bearing is lubricated at the factory; additional care is not required. Removing the caps and replacing / adding grease is strictly prohibited, as this entails a violation of the bearing. Possible conflict of lubricants.

Bearing marking varies by manufacturer:

Analogue according to GOST 1580205.

чертеж 1580205



Dimensions and main characteristics of the bearing:

  Internal diameter d - 25 mm;

  Outer diameter D - 52 mm;

  Bearing height / width B - 15 mm;

  Mass m - 0.130 kg;

  The maximum rotational speed in plastic lubricant npl - 8500 rpm;

  Load capacity in dynamics С - 14 kN;

  Capacity in statics Co - 7.8 kN.



The bearing exists only in one variation - closed by plastic covers.

It is widely used in agricultural machinery, combines, seeders.



All data specified in the specifications are for reference only.

Prices listed on the site are relevant at the time of ordering.
